IPv6 Hardware Access Control List (ACL) Commands
Software Reference for x310 Series Switches
36.20 AlliedWare Plus TM Operating System - Version 5.4.4C C613-50046-01 REV A
show ipv6 access-list (IPv6 Hardware ACLs)
Use this command to display all configured hardware IPv6 access-lists or the IPv6 access-
list specified by name. Omitting the optional access-list name parameter will display all
IPv6 ACLs.
Use the show ipv6 access-list standard command to display the IPv6 access-list specified
by name as defined from the
ipv6 access-list (named) command.
Syntax show ipv6 access-list []
show ipv6 access-list standard []
Mode User Exec and Privileged Exec
Examples To show the standard named ipv6 access-list acl_name use the following command:
Output Figure 36-1: Example output from the show ipv6 access-list standard command
To show all configured ipv6 access-lists use the command:
Output Figure 36-2: Example output from the show ipv6 access-list command
Related Commands ipv6 access-list (named)
(ipv6 access-list named ICMP filter)
(ipv6 access-list named protocol filter)
(ipv6 access-list named TCP UDP filter)
ipv6 traffic-filter
Parameter Description
standard Named standard access-list.
Hardware IPv6 access-list name.
awplus# show ipv6 access-list standard acl_name
Named Standard IPv6 access-list acl_name
deny any
awplus# show ipv6 access-list
IPv6 access-list deny_icmp
deny icmp any any vlan 1
IPv6 access-list deny_ssh
deny tcp abcd::0/64 any eq 22
