LLDP, LLDP-MED and Voice VLAN Introduction and Configuration

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

70.11

Configuring LLDP

You can configure LLDP on the device using either:

the command line interface. For detailed descriptions of the commands, see

Chapter 71, LLDP Commands

, or

SNMP—see

Chapter 69, SNMP MIBs

.

This section includes the following command line interface configuration procedures:

“Configure LLDP” on page 70.12

This procedure includes configuration for LLDP

between network connectivity devices; it does not include LLDP-MED. If you are
configuring LLDP-MED only, use the following procedure instead of this one.

“Configure LLDP-MED” on page 70.14

This procedure includes the LLDP

configuration required to support LLDP-MED, as well as specific LLDP-MED and Voice
VLAN configuration.

“Configure Authentication for Voice VLAN” on page 70.19

—This procedure

includes 802.1X port authentication configuration including dynamic VLAN
assignment to be used with LLDP-MED. Use the previous procedure before using this
one.

Because LLDP is often used together with SNMP, consider configuring SNMP before you
configure LLDP. LLDP transmits large amounts of data about the network. For security
reasons, we recommend configuring SNMP for SNMP version 3 only (for read and write
access). Remove all SNMPv1 and SNMPv2 configuration. See

Chapter 67, SNMP

Introduction

, and

Chapter 68, SNMP Commands

.
