Spanning Tree Commands

Software Reference for x310 Series Switches

19.54

AlliedWare Plus

TM

Operating System - Version 5.4.4C

C613-50046-01 REV A

spanning-tree mst instance restricted-role

Use this command in Interface Configuration mode for a switch port interface only to
enable the restricted role for an MSTI (Multiple Spanning Tree Instance) on a switch port.
Configuring the restricted role for an MSTI on a switch port prevents the switch port from
becoming the root port in a spanning tree topology.

Use the no variant of this command to disable the restricted role for an MSTI on a switch
port. Removing the restricted role for an MSTI on a switch port allows the switch port to
become the root port in a spanning tree topology.

Syntax

spanning-tree mst instance <instance-id> restricted-role

no spanning-tree mst instance <instance-id> restricted-role

Default

The restricted role for an MSTI instance on a switch port is disabled by default.

Mode

Interface Configuration mode for a switch port interface only.

Usage

The root port is the port providing the best path from the bridge to the root bridge. Use
this command to disable a port from becoming a root port. Use the no variant of this
command to enable a port to become a root port. See

Spanning tree operation

for root

port information.

Examples

Related Commands

instance vlan (MSTP)
spanning-tree priority (port priority)
spanning-tree mst instance
spanning-tree mst instance path-cost
spanning-tree mst instance restricted-tcn

Parameter

Description

<instance-id>

<1-15> Specify the MST instance ID. The MST instance must have
already been created using the

instance vlan (MSTP)

command.

awplus#

configure terminal

awplus(config)#

interface port1.0.2

awplus(config-if)#

spanning-tree mst instance 3
restricted-role

awplus#

configure terminal

awplus(config)#

interface port1.0.2

awplus(config-if)#

no spanning-tree mst instance 3
restricted-role
