QoS Commands

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

39.39

show mls qos interface policer-counters

This command displays an interface’s policer counters. This can either be for a specific
class-map or for all class-maps attached to the interface. If no class-map is specified then
all class-map policer counters attached to the interface are displayed.

Note that these counters are based on metering performed on the specified class-map.
Therefore, the ‘

Dropped Bytes

’ counter is the number of bytes dropped due to metering.

This is different from packets dropped via a ‘deny’ action in the ACL. If a policer is
configured to perform re-marking, bytes can be marked Red but are not dropped, and is
shown with a value of 0 for the Dropped field and a non-0 value for the ‘

Red Bytes

’ field.

Syntax

show mls qos interface <port> policer-counters

[class-map <class-map>]

Mode

User Exec and Privileged Exec

Usage

Note that the hardware does not record distinct counters for the number of Green or
Yellow bytes, so the field marked Green/Yellow is the summation of bytes that have been
marked Green or Yellow by the meter.

Example

To show the counters for all class-maps attached to port1.0.1, use the command:

Output

Figure 39-4: Example output from show mls qos interface policer-counters

This output shows a policer configured with remarking through ‘

action remark-

transmit

’, so although bytes are marked as Red, none are dropped. Therefore, the

Non-dropped Bytes

’ field shows a summation of Green/Yellow and Red bytes.

Parameter Description

<port>

Switch port.

class-map

Select a class-map.

<class-map>

Class-map name.

awplus#

show mls qos interface port1.0.1 policer-counters

awplus#show mls qos int port1.0.1 policer-counters
Interface: port1.0.1
Class-map: default
Green/Yellow Bytes: 0
Red Bytes: 0
Dropped Bytes: 0
Non-dropped Bytes: 0
Class-map: cmap1
Green/Yellow Bytes: 1629056
Red Bytes: 7003200
Dropped Bytes: 0
Non-dropped Bytes: 8632256
