EPSR Introduction and Configuration
Software Reference for x310 Series Switches
57.28 AlliedWare Plus TM Operating System - Version 5.4.4C C613-50046-01 REV A
Step 7: Add ports 1.0.1 and 1.0.2 to these VLANs (Configure on the
Master Node R-2)
On Rings 1 and 2 - Configure the Transit Nodes D and E
Step 1: Create the control and data VLANs (on Transit Nodes D and E)
awplus(config)#
interface port1.0.1,port1.0.2 Specify the ports (port1.0.1 and port1.0.2)
that you are configuring and enter the Interface
Configuration mode.
awplus(config-if)#
switchport mode trunk Set the switching characteristics of these ports to
Trunk mode.
awplus(config-if)#
switchport trunk allowed vlan add 40 Enable VLAN 40 on this port
awplus(config-if)#
exit Exit the Interface mode and enter the Global
Configuration mode.
awplus#
configure terminal Enter the Global Configuration mode.
awplus(config)#
vlan database Enter the VLAN Configuration mode.
awplus(config-vlan)#
vlan 5 name ctrl-blue state enable Enable VLAN 5 called ctrl-blue on the Transit
Node. Specifying the enable state allows
forwarding of frames on the VLAN-aware node.
awplus(config-vlan)#
vlan 40 name data-a state enable Enable VLAN 40 called data-a on the Transit
Node. Specifying the enable state allows
forwarding of frames on the VLAN-aware node.
awplus(config-vlan)#
vlan 6 name ctrl-green state enable Enable VLAN 6 called ctrl-green on the Transit
Node. Specifying the enable state allows
forwarding of frames on the VLAN-aware node.
awplus(config-vlan)#
exit Exit the VLAN Configuration mode and enter the
Global Configuration mode.
