background image

LLDP Commands

Software Reference for x310 Series Switches

71.46

AlliedWare Plus

TM

Operating System - Version 5.4.4C

C613-50046-01 REV A

Output

Figure 71-6: Example output from the show lldp neighbors detail command

awplus# show lldp neighbors detail interface port1.0.1
LLDP Detailed Neighbor Information:

Local port1.0.1:
Neighbors table last updated 0 hrs 0 mins 40 secs ago

Chassis ID Type .................. MAC address
Chassis ID ....................... 0004.cd28.8754
Port ID Type ..................... Interface alias
Port ID .......................... port1.0.6
TTL .............................. 120 (secs)
Port Description ................. [zero length]
System Name ...................... awplus
System Description ............... Allied Telesis router/switch, AW+ v5.3.3
System Capabilities - Supported .. Bridge, Router
- Enabled .... Bridge, Router
Management Addresses ............. 0004.cd28.8754
Port VLAN ID (PVID) .............. 1
Port & Protocol VLAN - Supported . Yes
- Enabled ... Yes
- VIDs ...... 5
VLAN Names ....................... default, vlan5
Protocol IDs ..................... 9000, 0026424203000000, 888e01, 8100,
88090101, 00540000e302, 0800, 0806, 86dd
MAC/PHY Auto-negotiation ......... Supported, Enabled
Advertised Capability ....... 1000BaseTFD, 100BaseTXFD, 100BaseTX,
10BaseTFD, 10BaseT
Operational MAU Type ........ 1000BaseTFD (30)
Power Via MDI (PoE) .............. [not advertised]
Link Aggregation ................. Supported, Disabled
Maximum Frame Size ............... 1522 (Octets)
LLDP-MED Device Type ............. Network Connectivity
LLDP-MED Capabilities ............ LLDP-MED Capabilities, Network Policy,
Location Identification,
Extended Power - PSE, Inventory
Network Policy ................... [not advertised]
Location Identification .......... [not advertised]
Extended Power Via MDI (PoE) ..... PD
Power Source ............ PSE
Power Priority .......... High
Power Value ............. 4.4 Watts
Inventory Management:
Hardware Revision ....... X1-0
Firmware Revision ....... 1.1.0
Software Revision ....... 5.3.3
Serial Number ........... M1NB73008
Manufacturer Name ....... Allied Telesis Inc.
Model Name .............. x900-12XT/S
Asset ID ................ [zero length]

Table 71-6: Parameters in the output of the show lldp neighbors detail command

Parameter

Description

Chassis ID Type

Type of the Chassis ID.

Chassis ID

Chassis ID that uniquely identifies the
neighbor.

Port ID Type

Type of the Port ID.

Port ID

Port ID of the neighbor.

TTL

Number of seconds that the information
advertised by the neighbor remains valid.

Port Description

Port description of the neighbor’s port.

System Name

Neighbor’s system name.
