IPv4 Hardware Access Control List (ACL) Commands

Software Reference for x310 Series Switches

34.12

AlliedWare Plus

TM

Operating System - Version 5.4.4C

C613-50046-01 REV A

<destination>

The destination address of the packets. You can specify a single
host, a subnet, or all destinations. The following are the valid
formats for specifying the destination:

any

Matches any destination IP address.

host

Matches a single destination host with
the IP address given by in
dotted decimal notation.

<ip-addr>/
<prefix>

An IPv4 address, followed by a forward
slash, then the prefix length. This
matches any destination IP address
within the specified subnet.

<ip-addr>
<reverse-mask>

Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255

is the same as entering

192.168.1.1/24

.

proto

Matches only a specified type of IP Protocol <1-255>.

<ip-protocol>

The IP protocol number, as defined by IANA (Internet Assigned
Numbers Authority

http://www.iana.org/assignments/

protocol-numbers

)

Protocol Number

Protocol Description [RFC Reference]

1

Internet Control Message [RFC792]

2

Internet Group Management [RFC1112]

3

Gateway-to-Gateway [RFC823]

4

IP in IP [RFC2003]

5

Stream [RFC1190] [RFC1819]

6

TCP (Transmission Control Protocol)
[RFC793]

8

EGP (Exterior Gateway Protocol) [RFC888]

9

IGP (Interior Gateway Protocol) [IANA]

11

Network Voice Protocol [RFC741]

17

UDP (User Datagram Protocol) [RFC768]

20

Host monitoring [RFC869]

27

RDP (Reliable Data Protocol) [RFC908]

28

IRTP (Internet Reliable Transaction
Protocol) [RFC938]

29

ISO-TP4 (ISO Transport Protocol Class 4)
[RFC905]

Table 34-4: Parameters in the access-list (hardware IP numbered) command - proto

Parameter(cont.)

Description(cont.)
