Spanning Tree Commands

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

19.23

show spanning-tree mst instance

This command displays detailed information for the specified instance, and all switch
ports associated with that instance.

A topology change counter has been included for RSTP and MSTP. You can see the
topology change counter for RSTP by using the

show spanning-tree

command. You can

see the topology change counter for MSTP by using the show spanning-tree mst
instance
command.

For information on output options, see

“Controlling “show” Command Output” on

page 1.37

.

Syntax

show spanning-tree mst instance <instance>

Mode

User Exec, Privileged Exec, and Interface Configuration

Usage

To display detailed information for instance 2, and all switch ports associated with that
instance, use the command:

Output

Figure 19-9: Example output from the show spanning-tree mst instance command

Parameter

Description

<instance>

Specify an MSTP instance in the range <1-15>.

awplus#

show spanning-tree mst instance 2

% 1: MSTI Root Path Cost 0 - MSTI Root Port 0 - MSTI Bridge Priority 32768
% 1: MSTI Root Id 80020000cd24ff2d
% 1: MSTI Bridge Id 80020000cd24ff2d
% port1.0.2: Port 5002 - Id 838a - Role Disabled - State Discarding
% port1.0.2: Designated Internal Path Cost 0 - Designated Port Id 838a
% port1.0.2: Configured Internal Path Cost 20000000
% port1.0.2: Configured CST External Path cost 20000000
% port1.0.2: CST Priority 128 - MSTI Priority 128
% port1.0.2: Designated Root 80020000cd24ff2d
% port1.0.2: Designated Bridge 80020000cd24ff2d
% port1.0.2: Message Age 0 - Max Age 0
% port1.0.2: Hello Time 2 - Forward Delay 15
% port1.0.2: Forward Timer 0 - Msg Age Timer 0 - Hello Timer 0
%
