IPv4 Hardware Access Control List (ACL) Commands
Software Reference for x310 Series Switches
34.22 AlliedWare Plus TM Operating System - Version 5.4.4C C613-50046-01 REV A
Mode IPv4 Hardware ACL Configuration
Default Any traffic on an interface controlled by a hardware ACL that does not explicitly match a
filter is permitted.
<source> The source address of the packets. You can specify a single host, a
subnet, or all sources. The following are the valid formats for
specifying the source:
<ip-addr>/
<prefix> An IPv4 address, followed by a
forward slash, then the prefix length.
This matches any source IP address
within the specified subnet.
<ip-addr>
<reverse-mask> Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255
is the same as entering
192.168.1.1/24 .
host Matches a single source host with the
IP address given by in
dotted decimal notation.
any Matches any source IP address.
<destination> The destination address of the packets. You can specify a single
host, a subnet, or all destinations. The following are the valid
formats for specifying the destination:
<ip-addr>/
<prefix> An IPv4 address, followed by a
forward slash, then the prefix length.
This matches any destination IP
address within the specified subnet.
<ip-addr>
<reverse-mask> Alternatively, you can enter a reverse
mask in dotted decimal format. For
example, entering 192.168.1.1
0.0.0.255
is the same as entering
192.168.1.1/24 .
host Matches a single destination host
with the IP address given by addr>
in dotted decimal notation.
any Matches any destination IP address.
icmp-type The ICMP type.
<icmp-value> The value of the ICMP
type.
Parameter(cont.) Description(cont.)
