EPSR Introduction and Configuration

Software Reference for x310 Series Switches

57.26

AlliedWare Plus

TM

Operating System - Version 5.4.4C

C613-50046-01 REV A

On Ring 2 - Configure the Master Node R-2

Step 1:

Create the control and data VLANs

(Configure on the Master Node R-2)

Step 2:

Add the control VLAN (ctrl-green) to the Ring Ports

awplus#

configure terminal

Enter the Global Configuration mode.

awplus(config)#

vlan database

Enter the VLAN Configuration mode.

awplus(config-vlan)#

vlan 6 name ctrl-green state enable

Enable vlan 6 called ctrl-green on the Master Node R-2.
Specifying the enable state allows forwarding of frames
on the VLAN-aware node.

awplus(config-vlan)#

vlan 40 name data-a state enable

Enable VLAN 40 called data-a on the Master Node R-2.
Specifying the enable state allows forwarding of frames
on the VLAN-aware node.

awplus(config-vlan)#

exit

Exit the VLAN Configuration mode and enter the Global
Configuration mode.

awplus(config)#

interface port1.0.1,port1.0.2

Specify the ports (port1.0.1 and port1.0.2)
that you are configuring, and enter the Interface
Configuration mode.

awplus(config-if)#

switchport mode trunk

Set the switching characteristics of these ports to
Trunk mode.

awplus(config-if)#

switchport trunk allowed vlan add 6

Enable vlan 6 on these ports.

awplus(config-if)#

switchport trunk native vlan none

Remove the native VLAN from these ring ports.
