DHCP Snooping Commands

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

56.33

To display detailed DHCP snooping ACL information for port 1.0.4, use the command:

Related Commands

access-list hardware (named)

show access-list (IPv4 Hardware ACLs)

Figure 56-9: Example output from the show ip dhcp snooping acl hardware command

awplus#show ip dhcp snooping acl hardware

DHCP Snooping Based Filters in Hardware:

Interface Access-list(/ClassMap) Source IP Source MAC
-----------------------------------------------------------------------------
port1.0.2 dhcpsn1 10.10.10.10 aaaa.bbbb.cccc
port1.0.2 dhcpsn1 20.20.20.20 0000.aaaa.bbbb
port1.0.2 dhcpsn1 0.0.0.0 0000.0000.0000
port1.0.2 dhcpsn1 0.0.0.0 0000.0000.0000
port1.0.2 dhcpsn1 0.0.0.0 0000.0000.0000
port1.0.2 dhcpsn1 0.0.0.0 0000.0000.0000
port1.0.3 dhcpsn2/cmap1 30.30.30.30 aaaa.bbbb.dddd
port1.0.3 dhcpsn2/cmap1 40.40.40.40 0000.aaaa.cccc
port1.0.3 dhcpsn2/cmap1 50.50.50.50 0000.aaaa.dddd
port1.0.3 dhcpsn2/cmap1 60.60.60.60 0000.aaaa.eeee
port1.0.3 dhcpsn2/cmap1 0.0.0.0 0000.0000.0000
port1.0.3 dhcpsn2/cmap1 0.0.0.0 0000.0000.0000
port1.0.3 dhcpsn2/cmap1 0.0.0.0 0000.0000.0000
port1.0.3 dhcpsn2/cmap1 0.0.0.0 0000.0000.0000
port1.0.4 dhcpsn3/cmap2 70.70.70.70
port1.0.4 dhcpsn3/cmap2 80.80.80.80
port1.0.4 dhcpsn2/cmap1 70.70.70.70
port1.0.4 dhcpsn2/cmap1 80.80.80.80
port1.0.4 dhcpsn1 70.70.70.70
port1.0.4 dhcpsn1 80.80.80.80

awplus#

show ip dhcp snooping acl detail interface port1.0.4

Figure 56-10: Example output from the show ip dhcp snooping acl detail interface command

awplus#show ip dhcp snooping acl detail interface port1.0.4

DHCP Snooping Based Filters Information:

port1.0.4 : Maximum Bindings ........... 2
port1.0.4 : Template filters ........... 7
port1.0.4 : Attached hardware filters .. 14
port1.0.4 : Current bindings ........... 1, 1 free
port1.0.4 Client 1 ................ 120.120.120.120
port1.0.4 : Templates: cheese (via class-map: cmap2)
port1.0.4 : 10 permit ip dhcpsnooping 100.0.0.0/8
port1.0.4 : Template: dhcpsn2 (via class-map: cmap1)
port1.0.4 : 10 permit ip dhcpsnooping any
port1.0.4 : 20 permit ip dhcpsnooping 10.0.0.0/8
port1.0.4 : 30 permit ip dhcpsnooping 20.0.0.0/8
port1.0.4 : 40 permit ip dhcpsnooping 30.0.0.0/8
port1.0.4 : Template: dhcpsn1 (via access-group)
port1.0.4 : 10 permit ip dhcpsnooping any mac dhcpsnooping abcd.0000.0000 00
00.ffff.ffff
port1.0.4 : 20 permit ip dhcpsnooping any
