VLAN Introduction

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

16.9

Associate the secondary VLANs with the primary VLAN

awplus(config-vlan)#

private-vlan 20 association

add 21

Associate secondary VLAN 21 with the
primary VLAN 20.

awplus(config-vlan)#

private-vlan 20 association

add 22

Associate secondary VLAN 22 with the
primary VLAN 20.

awplus(config-vlan)#

private-vlan 20 association

add 23

Associate secondary VLAN 23 with the
primary VLAN 20.

awplus(config-if)#

exit

Return to Global Configuration mode.

awplus(config-if)#

switchport mode private-

vlan promiscuous

Set the port as a promiscuous ports.

Set the other ports to be host
ports

awplus(config-if)#

exit

Return to Global Configuration mode.

awplus(config-if)#

switchport mode private-

vlan host

Set the ports as host ports.

On the promiscuous port, map the primary VLAN to each of the secondary VLANs

awplus(config-if)#

exit

Return to Global Configuration mode.

awplus(config-if)#

switchport private-vlan

mapping 20 add 21-23

Associate primary VLAN 20 and the
secondary VLANs 21 to 23 to the
promiscuous port.

Associate the community host ports with the community VLANs

awplus(config-if)#

exit

Return to Global Configuration mode.

awplus(config-if)#

switchport private-vlan

host-association 20 add 21

Associate primary VLAN 20 and secondary
VLAN 21 to the host ports.

awplus(config-if)#

exit

Return to Global Configuration mode.

awplus(config-if)#

switchport private-vlan

host-association 20 add 22

Associate primary VLAN 20 and secondary
VLAN 22 to the host ports.

Associate the isolated host ports with the isolated VLAN 23

Table 16-2: Configuration procedure for access mode private VLANs(cont.)
