background image

SNMP MIBs

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

69.13

AT-BOARDS-MIB

AT-BOARDS-MIB defines object identifiers for components of Allied Telesis products—
base CPU and expansion boards, interface types, and chip sets. Objects in this MIB have
the object identifier objects ({ atRouter 1 }), and are organized into the following groups:

Base CPU and expansion boards (

Table 69-3

). These object identifiers are for use with

the hrDeviceID object in the Host Resources MIB (see

“Public MIBs” on page 69.89

).

Interface types (

Table 69-4

).

Chip sets (

Table 69-5

).

Table 69-3: Object identifiers for base CPU and expansion boards

Object

Object Identifier

Description

boards

{ objects 1 }

pprx90024XT

{ boards 271 }

x900-24XT Enhanced Gigabit Layer 3+ Expandable Switch,
24 x 10/100/1000BASE-T copper ports (RJ-45 connectors),
2 x 20 Gigabit expansion bays

pprx90024XS

{ boards 272 }

x900-24XS Enhanced Gigabit Layer 3+ Expandable Switch,
24 x 10/100/1000BASE-T copper ports (RJ-45 connectors),
2 x 20 Gigabit expansion bays

pprAtXum10Gi

{ boards 273 }

XEM-1XP Expansion Module, 1 x 10Gbe XFP port

pprAtXum12SFPi

{ boards 274 }

XEM-12S Expansion Module, 12 x SFP Gigabit ports

pprAtXum12Ti

{ boards 275 }

XEM-12T Expansion Module, 12 x 10/100/100BASE-T
copper ports (RJ-45 connectors)

pprAtXum12TiN

{ boards 280 }

XEM-12T-N Expansion Module, 12 x 10/100/100BASE-T
copper ports (RJ-45 connectors), NEBS compliant

pprx90024XTN

{ boards 281 }

x900-24XT Enhanced Gigabit Layer 3+ Expandable Switch,
24 x 10/100/1000BASE-T copper ports (RJ-45 connectors),
2 x 20 Gigabit expansion bays, NEBS compliant

pprSwitchBladex908

{ boards 282 }

Switchblade x908 8 Slot Layer 3 Switch Chassis

pprx90012XTS

{ boards 288 }

AT-x900-12XT/S Advanced Gigabit Layer 3+ Expandable
Switch, 12 x combo ports (10/100/1000BASE-T copper or
SFP), 1 x 30Gbps expansion bay

pprAt9524TS

{ boards 290 }

x600-24Ts/XP, 24 x 1000BASE-T ports (RJ45 connectors),
4 x SFP (combo) ports

pprAt9524TSXP

{ boards 291 }

x600-24Ts/XP, 24 x 1000BASE-T ports (RJ45 connectors),
4 x SFP (combo) ports, 2 x XFP ports

pprAt9548TS

{ boards 294 }

x600-44Ts, 44 x 1000BASE-T ports, 4 x SFP ports

pprAt9548TSXP

{ boards 295 }

x600-44Ts/XP, 44 x 1000BASE-T ports, 4 x SFP ports, 2 x XFP
ports

pprXem2XP

{ boards 306 }

XEM-2XP Expansion Module, 2 x 10Gbe XFP port

pprATStackXG

{ boards 307 }

x600 Expansion Module, Stacking

pprATEMXP

{ boards 308 }

x600 Expansion Module, 2 x 10G XFP ports

pprATLBM

{ boards 309 }

x600 Expansion Module, loopback

pprAtSBx8112

{ boards 316 }

AT-SBx8112, SwitchBlade x8112 chassis

pprAtSBx81CFC400

{ boards 317 }

AT-SBx81CFC, Control Fabric Card for SwitchBlade x8112

pprAtSBx81GP24

{ boards 318 }

AT-SBx81GP24, 24 x 1G PoE line card
