SNMP MIBs

Software Reference for x310 Series Switches

69.10

AlliedWare Plus

TM

Operating System - Version 5.4.4C

C613-50046-01 REV A

Table 69-2: AT-ATMF MIB Objects

Object Object

Identifier

Description

atmf

{ modules 603 }

1.3.6.1.4.1.207.8.4.4.4.603

Root of the Allied Telesis ATMF MIB under the private(4)
node defined in RFC1155-SMI.

atAtmfTraps

{ atmf 0 }

207.8.4.4.4.603.0

Sub-tree of objects describing ATMF traps.

atAtmfBackup
StatusTrap

atAtmfTraps 1

This trap is generated when an ATMF master attempts to
backup a node’s FLASH contents. It states wether the
backup of an individual node, or all nodes, to a master node
has passed or failed. Its objects are:

1. atAtmfTrapNodeName

2. atAtmfTrapMasterNodeName
3. atAtmfTrapBackupStatus

atAtmfNode
StatusChange
Trap

atAtmfTraps 2

This trap is generated when an ATMF node joins or leaves
the ATMF network. It states whether a node has joined> an ATMF network. Its objects are:

1. atAtmfTrapNodeName

2. atAtmfTrapNodeStatusChange
3. atAtmfTrapNetworkName

atAtmfNode
RecoveryTrap

atAtmfTraps 3

This trap is generated when an attempt has been made to
recover an ATMF node. It states whether an attempt to
recover a node from the specified master has passed or
failed. Its objects are:

1. atAtmfTrapNodeName

2. atAtmfTrapMasterNodeName
3. atAtmfTrapNodeRecoveryStatus

atAtmfInterface
StatusChangeTrap

atAtmfTraps 4

This trap is generated when an ATMF interface status
change occurs. It states that an interface on a node has
changed status to either blocking or forwarding.

Its objects are:

1. atAtmfTrapNodeName

2. atAtmfTrapInterfaceName
3. atAtmfTrapInterfaceStatusChange

atAtmfExternal
MediaLowMemory
Trap

atAtmfTraps 5

This trap is generated when the available external storage
on the ATMF master node falls below a nominated
threshold. It states that the external USB or SD card storage
on a master node has fallen below the designated threshold
and specifies the total available memory and the
total free memory . Its objects are:

1. atAtmfTrapMasterNodeName

2. atAtmfTrapMediaType
3. atAtmfTrapMediaTotal
4. atAtmfTrapMediaFree

atAtmfRolling
RebootComplete
Trap

atAtmfTraps 6

This trap is generated when the ATMF rolling reboot process
has finished on a particular ATMF node. Nominally, it states
that the ATMF rolling reboot,

executed against the specified node, has returned a reboot
status of either failed or passed. Its objects are:

1. atAtmfTrapNodeName

2. atAtmfTrapRollingRebootStatus
