System Configuration and Monitoring Commands

Software Reference for x310 Series Switches

C613-50046-01 REV A

AlliedWare Plus

TM

Operating System - Version 5.4.4C

8.59

Output

Figure 8-27: Example output from the show system pluggable diagnostics command
on a switch

To display detailed information about the pluggable transceiver installed in port1.0.22
on a standalone switch, use the command:

Output

Figure 8-28: Example output from the show system pluggable diagnostics
port1.0.22 command on a switch

awplus#show system pluggable diagnostics
System Pluggable Information Diagnostics

Port1.0.21 Status Alarms Warnings
Reading Alarm Max Min Warning Max Min
Temp: (Degrees C) 29.387 - 100.00 -40.00 - 85.000 -10.00
Vcc: (Volts) 3.339 - 3.465 3.135 - 3.400 3.200
Tx Bias: (mA) 10.192 - 37.020 3.260 - 34.520 5.760
Tx Power: (mW) 17.872 - 35.643 8.953 - 28.313 11.271
Rx Power: (mW) 0.006 Low 15.849 0.025 Low 12.589 0.040
Rx LOS: Rx Down

Port1.0.22 Status Alarms Warnings
Reading Alarm Max Min Warning Max Min
Temp: (Degrees C) 29.387 - 100.00 -40.00 - 85.000 -10.00
Vcc: (Volts) 3.378 - 3.630 2.970 - 3.465 3.135
Tx Bias: (mA) 2.802 - 6.000 1.000 - 5.000 1.000
Tx Power: (mW) 2.900 - 11.000 0.600 - 10.000 0.850
Rx Power: (mW) 1.739 - 18.000 0.000 - 10.000 0.200
Rx LOS: Rx Up

awplus#

show system pluggable diagnostics port1.0.22

awplus#show system pluggable port1.0.22 diagnostics
System Pluggable Information Diagnostics

Port1.0.22 Status Alarms Warnings
Reading Alarm Max Min Warning Max Min
Temp: (Degrees C) 29.387 - 100.00 -40.00 - 85.000 -10.00
Vcc: (Volts) 3.378 - 3.630 2.970 - 3.465 3.135
Tx Bias: (mA) 2.802 - 6.000 1.000 - 5.000 1.000
Tx Power: (mW) 2.900 - 11.000 0.600 - 10.000 0.850
Rx Power: (mW) 1.739 - 18.000 0.000 - 10.000 0.200
Rx LOS: Rx Up
