732 Brocade Mobility RFS Controller CLI Reference Guide
53-1003098-01
7
--More--
rfs7000-37FABE(config-profile-71xxTestProfile-if-radio1)#
Related Commands:
wlan
interface-config-radio-instance
Enables a WLAN on this radio
Use this command to configure WLAN/BSS mappings for an existing access point deployment.
Administrators can assign each WLAN its own BSSID. If using a single-radio access point, there are
8 BSSIDs available. If using a dual-radio access point there are 8 BSSIDs for the 802.11b/g/n
radio and 8 BSSIDs for the 802.11a/n radio.
Supported in the following platforms:
• Access Points — Brocade Mobility 650 Access Point, Brocade Mobility 6511 Access Point,
Brocade Mobility 1220 Access Point, Brocade Mobility 71XX Access Point, Brocade
Mobility 1240 Access Point
Syntax:
wlan {bss|primary}
wlan {bss <1-8> {primary}}
Parameters
wlan {bss <1-8> {primary}}
Example
rfs7000-37FABE(config-profile-71xxTestProfile-if-radio1)#wlan TestWLAN
primary
rfs7000-37FABE(config-profile-71xxTestProfile-if-radio1)#show context
interface radio1
rf-mode sensor
placement outdoor
mesh client
rts-threshold 100
wireless-client tx-power 20
wlan TestWLAN bss 1 primary
off-channel-scan channel-list 2.4GHz 1
guard-interval long
aggregation ampdu tx-only
rifs tx-only
use association-acl-policy test
no Resets the transmit power indicated to wireless clients
{bss <1-8> |primary} Specify the WLAN name (it must have been already created and configured)
•
bss <1-8> – Optional. Specifies a BSS for the radio to map the WLAN
•
<1-8> – Specify the BSS number from 1 - 8.
•
primary – Optional. Uses the specified WLAN as the primary WLAN, when multiple WLANs exist
on the BSS
•
primary – Optional. Uses the specified WLAN as the primary WLAN, when multiple WLANs exist on
the BSS
