698 Brocade Mobility RFS Controller CLI Reference Guide
53-1003098-01
7
data-rates custom
[1|2|5.5|6|9|11|12|18|24|36|48|54||mcs-1s|mcs-2s|mcs-3s|basic-1|
basic-2|basic-5.5|basic-6|basic-9|basic-11|basic-12|basic-18|basic-24|basic-3
6|
basic-48|basic-54|basic-mcs-1s]
data-rates mcs qam-only
Usage Guidelines: (Supported data rates)
The following table defines the 802.11n MCS for MCS 1 streams, both with and without SGI:
custom Configures a list of data rates by specifying each rate individually. Use 'basic-' prefix before a rate to indicate
it’s used as a basic rate (For example, 'data-rates custom basic-1 basic-2 5.5 11')
•
1 – 1-Mbps
•
2 – 2-Mbps
•
5.5 – 5.5-Mbps
•
6 – 6-Mbps
•
9 – 9-Mbps
•
11 – 11-Mbps
•
12 – 12-Mbps
•
18 – 18-Mbps
•
24 – 24-Mbps
•
36 – 36-Mbps
•
48 – 48-Mbps
•
54 – 54-Mbps
•
mcs-1s – Applicable to 1-spatial stream data rates
•
mcs-2s – Applicable to 2-spatial stream data rates
•
basic-1 – Basic 1-Mbps
•
basic-2 – Basic 2-Mbps
•
basic-5.5 – Basic 5.5-Mbps
•
basic-6 – Basic 6-Mbps
•
basic-9 – Basic 9-Mbps
•
basic-11 – Basic 11-Mbps
•
basic-12 – Basic 12-Mbps
•
basic-18 – Basic 18-Mbps
•
basic-24 – Basic 24-Mbps
•
basic-36 – Basic 36-Mbps
•
basic-48 – Basic 48-Mbps
•
basic-54 – Basic 54-Mbps
•
basic-mcs-1s – Modulation and Coding Scheme data rates for 1 Spatial Stream
Refer to the Usage Guidelines (Supported data rates) section for 802.11an and 802.11ac MCS detailed
dates rates for both with and without short guard intervals (SGI).
mcs qam-only Configures supports for MCS QAM data rates only
MCS-1Stream Index Number of
Streams 20 MHz No SGI 20 MHz With SGI 40 MHz No SGI 20 MHz With SGI
0 1 6.5 7.2 13.5 15
1 1 13 14.4 27 30
2 1 19.5 21.7 40.5 45
3 1 26 28.9 54 60
4 1 39 43.4 81 90
5 1 52 57.8 108 120
