Example
The following example shows the IPSec site-to-site VPN tunnel ‘test’ settings
before the ‘no’ commands are executed:
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#show context
crypto map test 1 ipsec-isakmp
use ip-access-list test
security-association level perhost
peer 1 ikev2 ikev2Peer1
local-endpoint-ip 192.168.13.10
pfs 5
security-association lifetime kilobytes 250000t
security-association inactivity-timeout 200
transform-set AutVPN
ip nat crypto
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#no use
ip-access-list
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#no
security-association level perhost
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#no ip nat
crypto
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#no pfs
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#no
local-endpoint-ip
The following example shows the IPSec site-to-site VPN tunnel ‘test’ settings
after the ‘no’ commands are executed:
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#show context
crypto map test 1 ipsec-isakmp
peer 1 ikev2 ikev2Peer1
security-association lifetime kilobytes 250000
security-association inactivity-timeout 200
transform-set AutoVPN
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#1)#
The following example shows the IPSec remote VPN client ‘test’ settings before
the ‘no’ commands are executed:
rfs4000-229D58(config-device-00-23-68-22-9D-58-cryptomap-test#2)#show context
crypto map test 2 ipsec-isakmp dynamic
use ip-access-list test2
peer 1 ikev1 RemoteIKEv1Peer1
local-endpoint-ip 157.235.204.62
pfs 14
security-association lifetime seconds 10000
transform-set RemoteVPN
remote-type none
no pfs Removes the PFS configured for this auto site-to-site VPN tunnel
no remote-type Resets the remote VPN client type to default (XAUTH)
no security-association Removes the VPN tunnel or remote VPN client’s IPSec SA settings
no transform-set Removes the transform set applied to the VPN tunnel or remote VPN client
no use Removes IP access list applied to the auto site-to-site VPN tunnel or remote VPN client
