Brocade Mobility RFS Controller CLI Reference Guide 1165
53-1003098-01
21
Related Commands:
payload
signature mode commands
Configures payload settings. The payload command sets a numerical index pattern and offset for
this WIPS signature.
Supported in the following platforms:
• Access Points — Brocade Mobility 650 Access Point, Brocade Mobility 6511 Access Point,
Brocade Mobility 1220 Access Point, Brocade Mobility 71XX Access Point, Brocade
Mobility 1240 Access Point
• Wireless Controllers — Brocade Mobility RFS4000, Brocade Mobility RFS6000, Brocade
Mobility RFS7000
• Service Platforms — Brocade Mobility RFS9510
Syntax:
payload <1-3> pattern offset <0-255>
Parameters
payload <1-3> pattern offset <0-255>
Example
rfs7000-37FABE(config-test-signature-test)#payload 1 pattern brocade offset 1
rfs7000-37FABE(config-test-signature-test)#show context
signature test
bssid 11-22-33-44-55-66
dst-mac 55-66-77-88-99-00
frame-type assoc
filter-ageout 8
payload 1 pattern brocade offset 1
rfs7000-37FABE(config-test-signature-test)#
Related Commands:
src-mac
signature mode commands
Configures a source MAC address for a packet examined for matching
no Disables a WIPS signature
payload <1-3> Configures payload settings
•
<1-3> – Sets the payload index
pattern
Specifies the pattern to match: hex or string
•
– Sets the pattern name
offset <0-255> Specifies the payload offset to start the pattern match
•
<0-255> – Sets the offset value
no Removes payload and associated settings
