Host Adapter with Unsupported and Faulty SFP reports
The Adapters Faulty SFP report lists all Brocade adapters with unsupported or faulty small
form-factor pluggable (SFP) transceivers. This report is only available for Brocade adapters.
For adapters with unsupported SFPs, this report is the same as the Adapters Inventory report
filtered to show only those hosts with adapter ports that have unsupported SFPs. For a complete
list of fields and components of the Adapters Inventory report, refer to the
For adapters with degrading SFPs, there are additional columns in the table that show the
SFP/SFP+ and pluggable optical module (POM) properties for the degrading SFP.
Table 34
describes the SFP and POM fields of the Adapters Faulty SFP Report. For general report
content and table functions, refer to
“Report content and functions”
TABLE 34
Adapters Faulty SFP report fields and components
Field/Component
Description
SFP Supported
Whether the SFP is supported or not.
Connector Type
The type of port connector; for example, LC. SC, or Cu (copper cable).
Transceiver
The type of transceiver; for example, SFP or SFP+.
Media
The type of media for the transceiver; for example, single mode.
Speed
The port speed.
Extended ID
The identifier for the extended link.
Encoding
Displays how the extended link is encoded, for example, 8B10B.
Baud Rate
The transmission rate, roughly equivalent to the number of bits per second.
Length 9U1
The length of the single-mode fiber-optic cable, used in situations where gigabit
performance is not required (for distances greater than 100 meters).
Length 9U2
The length of the single-mode fiber-optic cable, used in situations where gigabit
performance is not required (for distances greater than 100 meters).
Length 50u
The length of the 50u fiber-optic cable (for distances greater than 10 meters).
Length 62.5u
The length of the 62.5u fiber-optic cable (for distances greater than 10 meters).
Length Cu
The length of the copper cable (for distances greater than 1 meter, where optimum
performance is required).
Vendor Name
The vendor of the extended link.
Vendor OUI
The vendor’s organizational unique identifier (OUI).
Vendor Part
The part number of the extended link.
Revision
The revision level of the extended link.
Wavelength
The wavelength translation, which enables longer reach through lower attenuation.
Options
Displays details about the transceiver; for example, the type of port connector, type of
transceiver, and enable/disable status.
BR Max
The upper bit rate limit at which the SFP transceiver meets its specifications.
BR Min
The lower bit rate limit at which the SFP transceiver meets it specifications.
Serial #
The serial number of the SFP transceiver.
Date Code
The date the SFP was manufactured transceiver.
