MAPS category, object, and measure hierarchy
50
MAPS category, object, and measure hierarchy
Fabric measures and events are organized in a hierarchy by category, object, and measure. There
is a category, object, and measure associated with every monitored behavior. Categories are the
highest level in the system, subdivided into one or more objects. Objects contain one or more
measures.
For a list of all categories, objects, and measures, refer to “MAPS categories, measures, and
actions” on page 1991.
MAPS structural elements
MAPS has the following structural elements: categories, groups, rules, and policies. Table 174
provides a brief description of each structural element.
Switch Resources TEMP — Temperature sensor N/A 1002
1003
1004
FLASH_USAGE — Flash usage % 1402
CPU — CPU usage % 1404
MEMORY_USAGE — Memory usage % 1404
1406
ETH_MGMT_PORT_STATE — Ethernet management port
state % N/A
FCIP CIR_STATE — FCIP circuit state changes N/A 3020
CIR_UTIL — FCIP circuit utilization % 3012
CIR_PKTLOSS — FCIP packet loss % 3016
Traffic Performance RX — Receive bandwidth usage percentage % 1186
TX — Transmit bandwidth usage percentage % 1190
UTIL — Trunk utilization % 1206
TX_FCNT — Tx Frame Count Count N/A
RX_FCNT — Rx Frame Count Count N/A
TX_THPUT — Tx Throughput Count N/A
RX_THPUT — Rx Throughput Count N/A
IO_RD — IO Read Command Count Count N/A
IO_WR — IO Write Command Count Count N/A
IO_RD_BYTES — IO Read Data mbps N/A
IO_WR__BY_TES — IO Write Data mbps N/A
1. Only valid for 16 Gbps, 10 Gbps, and QSFP transceivers.
TABLE 173 Fabric Watch supported RAS event IDs (Continued)
Category Measure Unit label RAS event ID
