Event action definitions
48
-
MIB Information, if you want the default SNMP name for the traps to be displayed.
-
MIB Alias, if you want the aliases for the traps to be displayed.
•
Use the Trap Filter tool to limit the trap list to the trap severities you want. To use this tool,
click the Filter button to display the Trap Filters dialog box.
6. After limiting the list of available traps, expand the MIB folder to which the trap you want
belongs under the Available Traps list and select that trap. Click the right arrow button to move
it to the Selected Traps list. You can select a trap in the Selected Traps list and view the trap
details in the Trap Details section.
7. If you selected Application Events in
, select the application events in the left list and use
the arrow button to move them to the right list.
8. If you selected Pseudo Events in
, select one or more of the pseudo events you created
that you want to include in the definition, then click the right arrow button to move it to the
Selected Pseudo Events list.
9. If you selected Custom Events in
, click Next to accept the defaults; otherwise, select the
Event Category, Severity, Message ID, and Description Contains, as required.
10. If you selected Snort® Message in
, select the Snort® messages in the left table and
use the arrow button to move them to the right.
To import Snort® rules, click the Import Snort® Rules button.
11. Select Configure varbind filters to configure filters on varbind values (refer to
on page 1934 for more information). If you do not want to configure varbind
filters, click Next.
The Sources pane of the Add Event Action dialog box is displayed. You can use the Search tool
to search for sources.
Configuring varbind filters
If actions must be confirmed based on a trap variable binding value (varbinds), select the
Configure varbind filters check box on the Events pane of the Add Event Action dialog box. This
enables you to configure filters on varbind values for this event action.
NOTE
Varbind filter configuration is only available if you selected Traps in
The varbinds for the selected trap are listed in the Available Varbinds list, shown in
Figure 862
.
To configure varbind filters for an event action, complete the following steps.
1. Select Monitor > Event Processing > Event Actions.
The Event Actions dialog box displays.
2. Click Next to advance to the Events pane.
