Brocade Network Advisor SAN + IP User Manual 2199
53-1003155-01
IP device properties
E
4. Click OK to close the dialog box.
Viewing VCS fabric properties
To view properties for a VCS fabric, complete the following steps.
1. Select Ethernet Fabrics from the view list on the Product List toolbar.
2. Right-click the VCS fabric in the Product List and select Properties.
The Fabric_Name Properties dialog box displays.
3. Review the device and port properties.
Connected switch \ Port The IP address of the switch connected to the AP. Also displays the port
number if the AP is directly connected.
Profile Name AP profile name.
RF Domain Name The RF domain name set for the AP.
Location Location set for the AP.
Contact Contact set for the AP.
Time Zone The time zone set for the AP.
Country The country set for the AP.
VLAN for Control Traffic The VLAN for control traffic set for the AP.
Client count The number of wireless clients or stations connected or associated to
the AP.
IP Address The IP address of the AP.
SFP/Port Optics tab Select to display the details of all the SFP and port optics.
NOTE: To export the SFP details, click the link under the Physical Ports -
SFP Details section of Detailed Report.
TX Power The power transmitted by the port in a device.
RX Power The power received by the port in a device.
Transceiver Temperature The temperature of the port, in Celsius.
TX Bias Current The current supplied to the SFP transceiver.
NOTE: To export power supply details, click the link under the
Chassis-Power Supply section of Detailed Report.
Wavelength The wavelength of the port.
Serial # The number to identify the port.
Media The type in which the port is present.
vNetwork Connectivity tab Select to display information about vNetwork connectivity for the fabric
members. For detailed information about this tab, refer to
“VM
Connectivity tab” on page 2752.
Flex Port Displays the ports which support Ethernet or Fibre Channel.
TABLE 232 IP device and port properties (Continued)
Field/Component Description
