Flow Vision flows
44
Flow frame type parameters
Frame monitoring can be performed for a variety of frames using predefined frame type
parameters. To access the Frame Type Picker dialog box, click the ellipsis button next to the Frame
Type field on the Add Flow Definition dialog box.
Table 150 lists the frame type parameters and the frames counted for each.
TABLE 149 Flow definition rules
Parameters Field names Rules
Port Ingress
Egress
•
Only one field must be specified
•
Values must be explicit
Frame Source
Destination
LUN
Frame Type
1
1. Refer to Table 150 for more information on frame types.
•
At least one field must be specified
•
Values for source and destination can be explicit or “*” (“*” indicates a
learned flow)
•
Values for LUN and frame type must be explicit
TABLE 150 Supported frame type parameters
Frame type parameter Frames counted
abts Abort sequence frames
baacc All frames accepted
barjt All frames rejected
scsi All SCSI frames (including both command and data frames)
scsiread Only SCSI read command frames
scsiwrite Only SCSI write command frames
scsirw Both SCSI read and write command frames
scsi2reserve Only SCSI 2 reserve command frames
scsi3reserve Only SCSI 3 reserve command frames
scsi2release Only SCSI 2 release command frames
scsi3release Only SCSI 3 release command frames
scsiresrel2 Only SCSI 2 reserve-release command frames
scsiresrel3 Only SCSI 3 reserve-release command frames
scsitur Only SCSI test unit ready frames
scsicmdsts Only SCSI command status frames
NOTE: This parameter is valid only for Flow Mirror. It implicitly assumes bidirectional flow
and looks for both SCSI command and status frames.
scsigoodstatus Only SCSI status frames with status marked as good (all 0s (zeros) in status byte)
scsicheckstatus Only SCSI status frames with check status (Check Condition, Busy, Reservation Conflict,
Task Full Set)
scsiinquiry Only SCSI inquiry frames
scsiresvconflict Only SCSI status frames with reservation conflict set
scsixferrdy Only SCSI FCP XFER_RDY (transfer ready) frames
