IP device properties
E
System OID
The system’s object identifier.
Product Type
The fabric’s product type, which is a Layer 2 switch.
Serial #
The VCS fabric member’s serial number.
VCS Mode
The VCS mode of the switch, which can be standalone or VCS fabric.
VCS ID
The VCS ID configured in the fabric.
Config Mode
The configuration mode of the fabric, which is Local Only or Distributed.
Licensed Features
The licensed features available on the device.
RBridge ID
The routing bridge identifier associated with the VCS fabric member.
Access Gateway Mode
Indicates whether the Access Gateway mode is enabled or disabled.
State
The device’s state (online or offline).
Fabric Status
The state of the fabric that is least operational, based on ISL status.
The possible states are: operational, unknown, degraded or failed.
Status
The health status of the switch.
Admin Status
The administrative status of the switch, for example, Normal.
Memo
Additional comments regarding the switch.
Vendor
The switch vendor.
Model
The switch model type (VDX 6710, VDX 6720, or VDX 6730).
Port Count
The number of ports on the switch.
Firmware
The firmware version and build number.
Location
The physical location of the product.
Contact
The name of the person or group you should contact about the product,
for example, Technical Support.
Description
The description of the product.
Connected AP Count
The number of AP devices connected to the device.
Add button
Click to add a user-defined property. For more information, refer to
Edit button
Click to edit a user-defined property. For more information, refer to
Delete button
Click to delete a user-defined property. For more information, refer to
Port Profiles tab
Select to display information about port profiles on the fabric.
Name
The name of the port profile (not editable). There are multiple default
profiles in a fabric (one per member).
Status
Port profile states can be one of the following, all of which are configured
using the command line interface:
•
Created
•
Activated
•
Associated
•
Applied
MAC Count
The number of MAC addresses associated with the port profile.
TABLE 233
VCS fabric properties (Continued)
Field/Component
Description
