Brocade Network Advisor SAN + IP User Manual 2179
53-1003155-01
Appendix
E
Device Properties
In this appendix
• Viewing SAN device properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2179
• Viewing VC module properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2193
• IP device properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2195
• Host properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2207
• Properties customization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2211
Viewing SAN device properties
You can customize the device and fabric Properties dialog boxes to display only the data you need
by creating user-defined property labels. You can also edit property fields to change information.
Viewing Fabric properties
To view the properties for a fabric, complete the following step.
1. Right-click any fabric and select Properties.
The Fabric_Name Properties dialog box displays, with information related to the selected
fabric.
To add user-defined property labels, refer to “Adding a property field” on page 2211.
Fields containing a green triangle ( ) in the lower right corner are editable.
TABLE 224 Fabric properties
Field/Component Description
Name The name specified through the switch Element Manager.
FID Fabric Name Enter a name for the fabric (up to 128 characters).
Supported on seed switches running Fabric OS 7.0 or later.
Seed Switch The IP address of the seed switch.
AD Enabled Whether admin domain is enabled on the switch or not.
Status The operational status.
Switch and AG Count The number of switches and Access Gateway’s in the fabric.
Description A description of the customer site.
Principal Switch The IP address of the principal switch.
Active Zone Configuration Whether active zone configuration is activated on the fabric.
