Network OS Fabric Watch violations with appropriate counter values are displayed for the following
categories. For SAN violations, the following categories display as blank.

Abnormal Frame Terminations — The number of frames abnormally terminated.

Symbol Errors — The number of undefined or invalid symbols received.

IFG (InterFrame Gap) Errors — The interframe gap between successive frames that is violated.

Customizing the Port Health Violations widget

You can customize the widget to display violations for a specific fabric and time frame.

To display data for a specific fabric or group, refer to

“Setting the network scope”

on page 261.

To display data for a specific duration, refer to

“Setting the time interval”

on page 263.

Sort the contents by clicking the column header. Click the same column header again to
reverse the sort order.

Performance monitors

The Management application provides the following preconfigured performance monitors:

TABLE 28

Preconfigure performance monitors

Monitor title

Description

Data collectors

Top Port Alignment Errors

Table view of the alignment errors measure

All SAN TE port collector

Top Port C3 Discards

Table view of the C3 discards measure

All SAN FC port collector

Top Port C3 Discards RX TO

Table view of the C3 discards RX TO measure. There are
four versions of this monitor based on the type of port: All
ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector

Top Port CRC Errors

Table view of the CRC errors measure. There are four
versions of this monitor based on the type of port: All
ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector, All SAN TE port
collector, Wireless ports collector

Top Port Discards

Table view of the discards measure

Port discard count collector

Top Port Encode Error Out

Table view of the encode error out measure. There are four
versions of this monitor based on the type of port: All
ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector

Top Port Errors

Table view of the errors measure

Port error count collector

Top Port Link Failures

Table view of the top port link failures. There are four
versions of this monitor based on the type of port: All
ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector

Top Port Link Resets

Table view of the top port link resets. There are four
versions of this monitor based on the type of port: All
ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector

Top Port Overflow Errors

Table view of the overflow errors measure

All SAN TE port collector

Top Port Receive EOF

Table view of the received end-of-frames measure

All SAN TE port collector

Top Port Runtime Errors

Table view of the runtime errors measure

All SAN TE port collector

Top Port Sync Losses

Table view of the top port synchronization losses. There
are four versions of this monitor based on the type of port:
All ports, initiator ports, ISL ports, and Target ports.

All SAN FC port collector
