Brocade Network Advisor SAN + IP User Manual
353
53-1003155-01
Reports
7
Fabric Ports/AG Port Details table
IP Address
The IP address of the switch.
Switch Name
The name of the switch. Click to launch the Switch Report.
Domain ID/ Port #
The domain ID and port number of the switch.
Zone
Whether the zone is online or offline.
Connected Device
Details about the connected device.
Device Name
The name of the connected device.
Device Vendor
The manufacturer of the connected device.
Device Type
The device type of the connected device. For example, Initiator or Target.
Connected Device/Switch
Port Wwn
The port world wide name of the connected device.
Port Name
The port name.
Port Speed (GBPS)
The port speed in gigabits per second.
Port Status
The port status. For example, Online, Offline, No light and so on.
Port State
The port state. For example, Online or Offline.
Port Type
The port type. For example, F-Port, L-Port, and so on.
Physical/Logical
Whether the switch is physical or logical.
Zone Aliases
The alternate name of the zone.
Bottlenecked Port Details table
IP Address
The IP address of the switch.
Switch Name
The switch name.
Domain ID /Port #
The domain ID of the switch.
Device Name
The name of the connected device.
Device Vendor
The vendor of the connected device.
Role
The role of the connected device.
Connected Device/Switch
WWN
The world wide name of the connected device.
Port Name
The switch port name.
Port Speed(Gbps)
The switch port speed.
Port Status
The switch port status.
Port Type
The switch port type.
Physical/Logical Port
Whether the port is Physical or Logical.
Zone Alias
The zone alias to which the switch port belongs.
Bottleneck Port Status
The current bottleneck port status.
N to F Port Details
IP Address
The switch IP address of the access gateway (AG).
Switch Name
The switch name of the AG.
TABLE 30
Fabric Ports report fields and components (Continued)
Field/Component
Description
