Emulex Drivers Version 10.2 for Linux User Manual
P010081-01A Rev. A
3. Configuration
Ethernet Driver Configuration
841
Notes:
On 4-port OCx11104 adapters, VFs can be configured only for ports 0 and 1, not
for ports 2 or 3.
VFs are supported for network functions only; they are not supported for
storage functions.
9. Detach VFs from the host before adding them to the guest.
Example 1 (using only one VF per physical port):
RHEL 6.x KVM: - View Emulex PCI devices with the lspci command:
# lspci | grep Emulex 16:00.0 Ethernet controller: Emulex
Corporation OneConnect 10Gb NIC (be3) (rev 03) <-- LOM Port 0 (Function 0)
16:00.1 Ethernet controller: Emulex Corporation OneConnect 10Gb NIC (be3)
(rev 03) <-- LOM Port 1 (Function 1) 16:04.0 Ethernet controller: Emulex
Corporation OneConnect 10Gb NIC (be3) (rev 03) <-- VF LOM Port 0 (Function
0) 16:08.0 Ethernet controller: Emulex Corporation OneConnect 10Gb NIC
(be3) (rev 03) <-- VF LOM Port 1 (Function 1
Table 3-5 Total VF Counts that are Supported for Various Adapter Configurations
Adapter Configuration
Number
of Ports
PF
Count
VF Count
per ASIC Comments
OCe11102 2-port 10Gb NIC,
stand-alone adapter
2
2
60
Per port VF count is 30.
P0/P1: 30/30
OCe11102 2-port 10G NIC,
stand-alone, NCSI-enabled IPL
2
2
59
VF count per port can be
P0/P1: 30/29 or P0/P1: 29/30.
OCm11102 2-port 10Gb, HP/IBM
LOM/Mezzanine
2
2
60
Per port VF count is 30.
P0/P1: 30/30
OCm11102 2-port 10Gb, HP/IBM
LOM/Mezzanine, NCSI-enabled
IPL
2
2
59
VF count per port can be
P0/P1: 30/29 or P0/P1: 29/30.
OCm11104 2-port 10Gb + 2-port
1Gb (4-port), IBM
LOM/Mezzanine
4
4
55
Per port VF count can be
P0/P1: 28/27 or P0/P1: 27/28.VFs
are not supported on 1G ports.
OCe11102 2-port 10G HP (All
IPLs)
2
4/6/8
48
Per port VF count is 24.
VFs will be distributed across the
PFs in multiples of 8.
OCe14401 1-port 40G NIC only
1
1
63
63 VFs for NIC port.
OCe14102 2-port 10G NIC only
2
2
62
Per port VF count is 31.
OCe14104 4-port 10G NIC only
4
4
124
Per port VF count is 31.
OCe14401 1-port 40G NIC plus
storage (iSCSI/FCoE)
1
2 (one
NIC, one
storage)
63
63 VFs for NIC port.
OCe14102 2-port 10G NIC plus
storage (iSCSI/FCoE)
2
4 (two
NIC, two
storage)
62
Per NIC port VF count is 31.
