Boot Version 10.2 for NIC, iSCSI, FCoE, and RoCE Protocols User Manual P010097-01B Rev. A
11. Configuring UEFI for Ethernet
Starting the Emulex NIC Configuration Utility
1634
Selecting Virtual LAN Mode
When virtual LAN mode is enabled, a VLAN tag can be used by iSCSI boot.
To enable virtual LAN mode:
1. On the Network Configuration screen (Figure 11-5), select Virtual LAN Mode and
press .
2. From the Virtual LAN Mode pop-up menu, select Enabled and press .
Configuring the Primary and Secondary Targets
To configure the iSCSI target parameters:
1. On the iBFT Configuration screen, select Primary Target or Secondary Target and
press .
Note: Configuration of the primary and secondary targets is identical. For this
reason, this section only covers the configuration of the primary target.
The Primary Target screen appears.
Figure 11-6 Primary Target Screen
The Primary Target screen enables you to configure the following items:

Boot target

iSCSI target name

Target’s IP version

Target’s IP address

Target’s ISID qualifier

Target’s TCP port

Target’s boot LUN
