Boot Version 10.2 for NIC, iSCSI, FCoE, and RoCE Protocols User Manual P010097-01B Rev. A
2. Configuring PXE Boot for NIC on LPe16202, OCe10100, and OCe11100-series Adapters
PXE Boot Parameters Default Values
1533
Note: An LPVID is optional for IBM Virtual Fabric Mode, but it is required for
every function when using Switch Independent Mode.
Note: When IBM Virtual Fabric Mode or Unified Fabric Protocol Mode is enabled, you
must configure the minimum and maximum bandwidth settings on the switch.
PXE Boot Parameters Default Values
The default settings for the PXE Boot parameters are listed in the following table.
Table 2-2 PXE Boot Parameter Default Values
Parameter Default Value Valid Values
Advanced Mode Enabled (OCe11100-series 2-port and
4-port controllers and the
LPe16202/OCe15100 CFA)
Disabled (OCe10100-series controllers) Enabled
Disabled
PXE Boot Support The default for this parameter varies
depending on the vendor
configuration. Enabled
Disabled
SR-IOV Disabled Enabled
Disabled
VLAN Support Disabled Enabled
Disabled
VLAN ID 0 0–4094
VLAN Priority 0 0–7
Multichannel Mode The default for this parameter varies
depending on the vendor
configuration. For Emulex adapters:
• Enabled
• Disabled
For IBM adapters:
• IBM Virtual Fabric Mode
• IBM Unified Fabric Protocol Mode
• Switch Independent Mode
• Disabled
Minimum Bandwidth 0% Must have a total of 100% across all
ports.
Maximum Bandwidth 0% From the minimum bandwidth value up
to 100% (inclusive).
LPVID 0 2–4094
