OneCommand™ Manager Application P010066-01A Rev. A
8. Managing Adapters and Ports
OCe14000-Series Adapters
228
UFP Configuration
When UFP is selected, the Adapter Configuration tab looks like the following:
Figure 8-82 MultiChannel UFP View (concurrent mode storage)
The Channel Configuration table shows the channel properties for UFP. Additionally,
the protocol can be configured on the second and third channels including NIC .
UFP Configuration Rules
There are drop-down menus for each port's 2nd and 3rd channels. UFP channel
protocol assignments are subject to the following rules:

The first channel is always NIC.

NIC + RoCE cannot be configured with UFP.

The 2nd and 3rd channels can be assigned the following:

NIC

None (channel disabled)

Storage protocol (note: on 3rd channel only when concurrent mode storage
is available)

The 4th and higher channels of a port (if available) can be assigned NIC or
None.
Dell NPar Configuration View
Note: For NPar, functions are referred to as partitions.
Note: SR-IOV must be disabled on the adapter BIOS when NPar is used. See
“Enabling and Disabling SR-IOV on NIC Ports” on page 190 for information on
disabling SR-IOV on the adapter BIOS.
