Boot Version 10.2 for NIC, iSCSI, FCoE, and RoCE Protocols User Manual P010097-01B Rev. A
11. Configuring UEFI for Ethernet
Starting the Emulex NIC Configuration Utility
1649
4. When you are finished configuring LPVIDs, press to return to the Controller
Configuration screen.
Saving the Configuration
To save the configuration changes, on the Controller Configuration screen, select Save
Configuration and press .
Configuring Multichannel for IBM Adapters
Note: This section only pertains to certain Emulex OneConnect adapters that support
IBM Virtual Fabric multichannel or Unified Fabric Protocol.
Multichannel provides the ability to configure multiple PCI functions or I/O channels
for each adapter port.
Note: Setting up IBM Virtual Fabric or UFP multichannel depends on cooperation
with adjacent switches.
To enable multichannel support:
1. On the Emulex NIC Selection screen, select Multichannel Mode and press .
The Multichannel Mode pop-up menu appears.
Figure 11-18 Multichannel Mode Dialog Box
2. Select one of the following settings and press :

Switch Independent Mode

IBM Virtual Fabric Mode

IBM Unified Fabric Protocol Mode
