4. Using the OneCommand Manager Application
The OneCommand Manager Application Window Element Definitions
82
The iSCSI icon represents an iSCSI PCI function instance. iSCSI functions can support up to
sixteen logical adapters, with each logical adapter appearing in the discovery-tree as a
separate child node under the respective iSCSI function. A green iSCSI icon represents an iSCSI
PCI function on-line instance. A black iSCSI icon represents an iSCSI PCI function port-disabled
instance. A red iSCSI icon represents an iSCSI PCI function link down instance.
A green FCoE icon represents an FCoE PCI function on-line instance. A black FCoE icon
represents an FCoE PCI function port-disabled instance. A red FCoE icon represents an FCoE
PCI function link down instance.
The NIC icon represents a NIC-Only PCI function instance. A green icon indicates this function
instance is on-line, black indicates it is disabled, and red indicates a link down instance.
The RoCE icon represents a NIC + RoCE function on the selected port.
The ASIC node icon, only displayed for OneConnect dual ASIC 4 port 8Gb/s FC adapters,
represents each ASIC on the adapter. Each ASIC is managed independently. The ASIC node
format “ASIC bus#-sub-adapter#” represents the PCI bus number and the sub-adapter number,
which is a concatenation of the discovered port numbers for the ASIC. For example, “ASIC
64-12” represents PCI bus number 64, and 12 represents ports 1 and 2. If there were no
discovered functions for a port on that ASIC, the label would be “ASIC 64-2” (port 1 is
missing).
The Virtual Port icon represents a virtual port.
The COMSTAR icon represents COMSTAR target mode ports. COMSTAR ports are unique in that
a single port can be shown simultaneously as both a manageable adapter port and a regular
target. When a COMSTAR port is seen as a target, it displays the Target discovery-tree icon
and Target dialog box information. A COMSTAR icon with a red X indicates the link is down.
(COMSTAR ports are supported on OpenSolaris only.)
The Target icon represents connections to individual storage devices.
The LUN icon represents connections to individual disk LUNs.
The masked LUN icon represents a LUN not presented to the host.
The ExpressLane LUN icon represents a LUN with ExpressLane priority queueing enabled.
The Media Exchanger icon represents connections to individual media exchangers. A media
exchanger is a jukebox-like device that is capable of swapping various media device instances
(such as records or CDs) in and out.
The Tape LUN icon represents LUNs that are tape devices.
The Target Controller LUN icon represents LUNs that are storage controllers.
The Switch icon represents connections to the switch.
