Emulex Adapter Installation Manual P010288-01A Rev. A
2. Installation
Viewing the LEDs
1815
Note: For the Link Rate conditions, there is a 1 second pause when the LED is off
between each group of fast blinks (2, 3, or 4). Observe the LED sequence for
several seconds to be sure you have correctly identified the pattern.
Table 2-1 FC Adapter LED Activity
Green LED Yellow LED State
Off Off Boot failure (Dead board)
Off On POST failure (Dead board)
Off Slow Blink Boot failure after POST
Off Flashing POST processing in progress
On Off Failure in Common Code Module
On On Failure in Common Code Module
On 1 Fast Blinks Normal (Link up at 2GFC) (legacy
compatibility only)
On 2 Fast Blinks Normal (Link up at 4GFC)
On 3 Fast Blinks Normal (Link up at 8GFC)
On 4 Fast Blinks Normal (Link up at 16GFC)
Slow Blink Off Normal-link down
Fast Blink Fast Blink Beaconing
