OneCommand Manager for VMware vCenter Version 10.2 User Manual P010089-01A Rev. A
6. Managing Adapters and Ports
OCe14100–Series Adapters
1280

Both the minimum and maximum bandwidth for the channels assigned None
are set to 0.

The LPVIDs are set to 0. You must assign any NIC channel a valid LPVID.
Note: These rules create the default settings for the channels. You can update these
rules before saving them.
IBM MultiChannel Configuration View
Note: IBM multichannel currently only allows four channels per port even in one and
two port configurations
For IBM multichannel configuration, there are three different multichannel types
available: vNIC, SIMode, and UFP. When you check the MultiChannel radio button,
the Adapter Configuration tab looks like the following:
Figure 6-62 MultiChannel View (showing multichannel type drop-down)
A MultiChannel Type pull down menu is available to select the type of multichannel
configuration on the adapter. The contents of the Channel Configuration table depend
upon the selected multichannel type.
Multichannel vNIC Configuration
When vNIC is selected on the adapter, the Adapter Configuration tab looks like the
following:
