Boot Version 10.2 for NIC, iSCSI, FCoE, and RoCE Protocols User Manual P010097-01B Rev. A
Appendix F. Dell UEFI
Main Configuration Page
1777
iSCSI Second Target Parameters Page
This page allows you to enable a connection for the second iSCSI target and configure
parameters.
Figure F-11 iSCSI Second Target Parameters Page
Table F-10 iSCSI Second Target Parameters Page Menu Options
Menu Option Description and Available Settings
Connect Enable connecting to the second iSCSI target.
Available settings include:
• Enabled
• Disabled (default)
IP Address Specify the second target’s IP address. The value should be in either
IPv4 or IPv6 format and can be 2–39 characters long.
TCP Port Specify the second target’s TCP port number. The valid range is
1–65535.
Boot LUN Specify the second iSCSI storage target’s boot LUN. The valid range
is 0–18446744073709551615.
iSCSI Name Specify the second iSCSI storage target’s initiator IQN. The valid
range is 0–223 characters.
CHAP ID Specify the second ISCSI storage target’s CHAP ID. The valid range is
0–128 characters in length. If only a single value of the CHAP ID is
supported for all targets, then it is stored here.
CHAP Secret Specify the second ISCSI storage target’s CHAP Secret. The valid
range is 0 or 12–16 characters in length. If only a single value of the
CHAP Secret is supported, then it is stored here.
