OneCommand™ Manager Application

P010066-01A Rev. A

8. Managing Adapters and Ports

OCe14000-Series Adapters

232

Figure 8-85 Adapter Configuration Tab with NPar and NParEP Mode Enabled (2 port configuration)

When NParEP Mode is enabled on two port adapters, up to eight partitions per port

can be configured.

Figure 8-86 Adapter Configuration Tab with NPar and NParEP Mode Enabled (4 port configuration)

Four port adapters allow up four partitions per port to be configured when NParEP

Mode is enabled.
NPar protocol assignments are subject to the following rules:
