OneCommand Manager for VMware vCenter Version 10.2 User Manual P010089-01A Rev. A
7. Updating Firmware
Performing a Batch Firmware Update in Cluster View
1294
2. Click Browse and a search dialog box appears. On the search dialog box, select the
file you want to use and click OK. A status message appears indicating that
OneCommand Manager for VMware vCenter is searching for compatible adapters.
Once compatible adapters are found, the following is displayed in the Batch
Firmware Download dialog box:

The Firmware File field shows the selected image file name.

The Supported Models field shows a list of all adapter models that are
compatible with the selected image file.

The set of compatible adapters appears in the dialog box’s tree-view.
3. To view the compatible adapters in host-centric mode, make sure the Group by
Fabric checkbox is cleared. Figure 7-2 shows the Batch Firmware Download dialog
box in host-centric view.
Figure 7-2 Batch Firmware Download Dialog Box, Host-Centric View
4. To view the compatible adapters in a fabric-centric mode, select the Group by
Fabric checkbox. Figure 7-3 shows the Batch Firmware Download dialog box in
fabric-centric view
