Emulex Drivers Version 10.2 for VMware ESXi User Manual P010087-01A Rev. A
4. Troubleshooting
Troubleshooting the FC/FCoE Driver
1037
LPFC Log Messages
Log messages have traditionally been organized into logical groups based on code
functionality in the FC driver. With the introduction of the latest Emulex adapters, that
grouping is modified to account for additional behaviors. The traditional grouping is
maintained, but recently added messages are no longer grouped together.
The messages provided in this section are unmaskable error conditions. They are
automatically added to the system console log.
You can examine the /var/log/vmkernel file.log to see any of these messages. If you
have concerns, the best policy is to run a vm-support dump and contact VMware or
Emulex support staff.
Log messages are organized into logical groups based on code functionality within the
driver. Each group consists of a block of 100 log message numbers. Most groups require
a single block of 100 message numbers, however some groups (INIT, FCP) require two
blocks.
Table 4-2 lists the groups and defines the associated number ranges for ESXi 5.0 and 5.1
systems.
Table 4-3 lists the groups and defines the associated number ranges for ESXi 5.5
systems.
Table 4-2 Message Log Table for ESXi 5.0 and 5.1 Systems
LOG Message Verbose Mask Definition Verbose Bit Verbose Description
LOG_ELS 0x1 ELS events
LOG_DISCOVERY 0x2 Link discovery events
LOG_MBOX 0x4 Mailbox events
LOG_INIT 0x8 Initialization events
LOG_LINK_EVENT 0x10 Link events
LOG_FCP 0x40 FCP traffic history
LOG_NODE 0x80 Node table events
LOG_TEMP 0x100 Temperature sensor events
LOG_MISC 0x400 Miscellaneous and FCoE events
LOG_SLI 0x800 SLI events
LOG_FCP_ERROR 0x1000 Selective FCP events
LOG_LIBDFC 0x2000 IOCTL events
LOG_VPORT 0x4000 NPIV events
LOG_EVENT 0x10000 IOCTL event
LOG_DAEMON 0x20000 IOCTL Daemon events
LOG_FIP 0x40000 FIP event
LOG_PROC 0x80000 Procfs events
