14. Troubleshooting
Troubleshooting for the NIC Protocol
1714
PXE-E55: Proxy DHCP service
did not reply to request on port
4011. The client issued a proxyDHCP
request to the DHCP server on
port 4011 but did not receive a
reply. Check that the DHCP server and
TFTP server are properly
configured on different servers.
This issue may happen only when
both are configured on separate
servers.
UNDI Error Codes
PXE-E60: Invalid UNDI API
function number The underlying UNDI drivers do
not support the UNDI API sent
from BaseCode/NBP. Check with the hardware vendor.
PXE-E61: Media test failed,
check cable. There is no physical link on the
PXE client port on which the boot
is attempted. Check the cables on the NIC
interface.
PXE-E63: Error while initializing
the NIC. There is an issue in initializing the
hardware as part of the
UNDI_Initialize API. Check with the hardware vendor.
BaseCode/UNDI Loader Error Codes
PXE-EC1: BaseCode ROM ID
structure was not found. The UNDI boot module can not
find the BaseCode ROM ID
structure. This may be caused by
a corrupted BaseCode ROM image.
PXE-EC3: BaseCode ROM ID
structure is invalid. The BaseCode ROM ID structure is
invalid. This may be caused by a
corrupted BaseCode image in
ROM.
PXE-EC4: UNDI ROM ID structure
was not found. The BaseCode loader module
could not locate the UNDI ROM ID
structure. The UNDI ROM image is
probably corrupted.
PXE-EC5: UNDI ROM ID structure
is invalid. The UNDI ROM image is probably
corrupted.
PXE-EC8:!PXE structure was not
found in UNDI driver code
segment. The UNDI ROM image is probably
corrupted.
Bootstrap and Discovery Error Codes
PXE-E74: Bad or missing PXE
menu and /or prompt
information PXE tags were detected but the
boot menu and/or boot prompt
were not found or were invalid.
Table 14-1 PXE Error Codes (Continued)
Error Codes Possible Reason Comment/Solution
