Dell Emulex Family of Adapters - Manual (Page 110)

OneCommand™ Manager Application P010066-01A Rev. A
7. Managing Hosts
Grouping Hosts
110

Restore All Groups – Returns all groups to their original state.

OK – Saves the current configuration changes and closes the dialog box.

Cancel – Discards changes and closes the dialog box.
Host Group Management Icons

Indicates the host is currently assigned to a single host group.

Indicates the host is currently assigned to multiple host groups.
Creating a Host Group
To create a new host group:
1. From the View menu, select Manage Groups. The Host Group Management dialog
box appears.
2. Click Create New Group. The Create New Host Group dialog box is displayed.
Figure 7-4 Create New Host Group Dialog Box
3. Enter the name of the group you want to create and click OK. The new group
appears in the Groups list on the Host Group Management dialog box.
Deleting a Host Group
To delete a host group:
1. From the View menu, select Manage Groups. The Host Group Management dialog
box appears.
2. From the Groups list, select the group you want to delete. The Host Group
Management warning dialog box appears.
Figure 7-5 Host Group Management Warning Dialog Box
3. Click Yes to delete the selected host group.
