Boot for the Fibre Channel Protocol User Manual P010096-01A Rev. A
4. Emulex BIOS Utility
Configure Adapter Parameters
1426
3. Select the retry timer interval.
4. Press until you exit the BIOS utility.
5. Reboot the system
Change Topology
Emulex drivers support arbitrated loop and point-to-point topologies. If it is necessary
to change the topology, do so before you configure boot devices. The default topology
is auto topology with loop first. For FC-AL, each adapter has a default ALPA of 01
(Hex).You can configure:

Auto topology with loop first – default

Auto topology with point-to-point first

FC-AL

Fabric point-to-point
To select the adapter topology:
1. On the main configuration menu (Figure 4-2), select Configure Advanced Adapter
Parameters. The adapter configuration menu is displayed (Figure 4-9).
2. Select Topology Selection. Information similar to Figure 4-12 is displayed.
Figure 4-12 Topology Menu
3. Select the topology for the adapter.
4. Press until you exit the BIOS utility.
5. Reboot the system.
