Emulex Drivers for Windows User Manual P010077-01A Rev. A
3. Configuration
NIC Driver Configuration
647
you select Disabled, only the first PCI functions on each port are powered-on
and present. None of the PCI function parameters can be changed. If you select
NPar, NPar is enabled and the PCI function parameters can be modified (see
“Enabling NPar Using the Multichannel Property Page” on page 645).

Factory Default — restores the adapter to its factory default settings. A system
reboot is required for the changes to take an effect.

Port tab — lists all of the ports available on the adapter. Each row in the list
view corresponds to a single PCI function and contains all PCI function
parameters. The PF column contains the PCI function number of the device. The
Name column provides a friendly device name if one is available. Otherwise,
the name is a generic operating system device class name.
Note: If you cancel the configuration change and return the device to its factory
default state, a reboot is still required.
PCI Function Presentation Using NPar
Table 3-6 PCI Function Representation for a Two-Port Adapter
Port Partition Function Personality
1 1 0 NIC
2 2 NIC | iSCSI | FCoE | None
3 4 NIC | iSCSI | FCoE | None
4 6 NIC | iSCSI | FCoE | None
2 1 1 NIC
2 3 NIC | iSCSI | FCoE | None
3 5 NIC | iSCSI | FCoE | None
4 7 NIC | iSCSI | FCoE | None
Table 3-7 PCI Function Representation for a Four-Port Adapter
Port Partition Function Personality
1 1 0 NIC
2 4 NIC | iSCSI | FCoE | None
2 1 1 NIC
2 5 NIC | iSCSI | FCoE | None
3 1 2 NIC
2 6 NIC | iSCSI | FCoE | None
4 1 3 NIC
2 7 NIC | iSCSI | FCoE | None
