OneCommand™ Manager Application P010066-01A Rev. A
4. Using the OneCommand Manager Application
The OneCommand Manager Application Window Element Definitions
80
Note: You cannot change host names using the OneCommand Manager application; names
must be changed locally on that system.
• Displays the installed adapters within each host system.
• Displays adapter ports and the port numbers if available.
• Displays adapters by the WWNN if multiple adapters have the same model number.
• Displays the WWPN if targets are present. Multiple adapters can refer to the same target.
• Displays the LUN number if LUNs are present.
• COMSTAR ports are located on the same level in the discovery-tree as initiator ports,
meaning that they branch out from adapters. Unlike initiator ports, however, targets do
not branch out from COMSTAR ports. (COMSTAR ports are supported on OpenSolaris only.)
Fabric View button
• Displays the FC/FCoE fabrics in the SAN with their fabric IDs.
• Displays the ports under each switch.
• If targets are present, displays each WWPN. Multiple adapters can refer to the same
target.
• If LUNs are present, displays each LUN number.
• If the fabric ID is all zeros, no fabric is attached.
Note: iSCSI and NIC ports are not displayed in Fabric View.
Virtual Ports View button
• Displays virtual ports in the SAN.
Note:
• The Emulex emlxs driver for Solaris does not support COMSTAR running over virtual ports,
so the Virtual Ports view only displays initiator ports.
• COMSTAR ports are supported on OpenSolaris only.
• SCSI and NIC ports are not displayed in Virtual Ports View.
Local HBAs Only button
• Displays only local adapters.
Show Host Groups button and menu
• Displays hosts by their associated groups.
• Displays available host groups.
Find Host button and search field
• Enables you to search by host name for a particular host in the discovery-tree.
Refresh LUNS button
• Initiates a LUN discovery refresh cycle.
Help button
• Displays the OneCommand Manager application’s online help.
• Displays the About OneCommand Manager dialog box. The dialog box displays version
information including; RMAPI, Discovery, DFClib, MILI Service Version, MILI Library Version
(Windows) and Remote Management Agent Version (Windows). It also enables you to
contact Emulex Technical Support.
