Dell Emulex Family of Adapters - Manual (Page 1226)

OneCommand Manager for VMware vCenter Version 10.2 User Manual P010089-01A Rev. A
6. Managing Adapters and Ports
iSCSI Port
1226
iSNS Tab Field Definitions
iSNS Server

IP Address - The IP address of the iSNS server.

TCP Port - The TCP port number for the connection to the iSNS server.
Disabling the iSNS Server
To disable the iSNS server, click Clear iSNS on the iSNS tab.
Changing the iSNS Server
To change the iSNS server:
1. On the iSNS tab, click Add/Update iSNS. The Update iSNS Server dialog box is
displayed.
Figure 6-25 iSCSI Port, Update iSNS Server Dialog Box
2. Enter the new server address and Port ID.
3. Click OK to commit the new iSNS server. The new iSNS information is displayed
on the iSNS tab. The new or updated iSNS server is also queried for iSCSI targets.
Any discovered targets are added to the iSCSI Target Discovery tab.
Viewing iSCSI Initiator Statistics
The iSCSI Statistics tab shows information for the selected iSCSI port.
To view iSCSI initiator statistics:
1. Select a host in the vSphere console tree-view and select the Emulex OneCommand
tab.
2. In the Emulex Device Management tree-view, select the iSCSI initiator for which
you want to view Statistic information.
3. Click the iSCSI Statistics tab.
