OneCommand™ Manager Application P010066-01A Rev. A
8. Managing Adapters and Ports
FC/FCoE
125

Part Number – The part number provided by the SFP vendor.

Revision – The vendor revision level.
Diagnostic Data Area

Temperature – The internally measured module temperature.

Supply Voltage – The internally measured supply voltage in the transceiver.

TX Bias Current – The internally measured transmitted bias current.

TX Output Power – The measured transmitted output power.

RX Input Power – The measured received input power.
Viewing FC/FCoE VPD Information
The VPD tab displays vital product data (if available) for the selected FC adapter port
such as the product name, part number, serial number and so on.
To view VPD information:
1. Select Host or Fabric view.
2. In the discovery-tree, select the FC/FCoE port whose VPD information you want to
view.
3. Select the VPD tab.
Figure 8-8 FC/FCoE VPD Tab
VPD Table Definitions

Product Name – Product information about the selected adapter port.

PN (Part Number) – The adapter's part number.

SN (Serial Number) – The adapter's serial number.

VO – Vendor unique data. “V” indicates a vendor-specific field. An adapter
may have none, one or more of these fields defined. Valid values for this field
are “VO” (the letter “O”, not the number zero) and “Vx” (where “x” is a
number).
