Emulex Drivers for Windows User Manual P010077-01A Rev. A
3. Configuration
NIC Driver Configuration
650
Figure 3-21 The Multichannel Property Page with NPar Enabled and NParEP Enabled
Multichannel Property Page with NPar and NParEP Enabled
To enable NParEP, select the NParEP checkbox. When NParEP is enabled, the PCI
functions in Table 3-8 or Table 3-9 become visible.
PCI Function Presentation Using NParEP
Note: When using host tools that allow you to configure partitions, you can select an
option of "None" for a PCI function. When this option is applied, the selected
PCI function does not appear on the PCI scan.
Table 3-8 PCI Function Representation for a 2-Port 16-Function Adapter—NParEP Enabled
Port Partition Function Personality
1 1 0 NIC
2 2 NIC | iSCSI | FCoE | None
3 4 NIC | iSCSI | FCoE | None
4 6 NIC | iSCSI | FCoE | None
5 8 NIC | None
6 10 NIC | None
7 12 NIC | None
8 14 NIC | None
