Troubleshooting the iSCSI Driver
1140
Examples
The following is an example of Default Initiator name and Data Digest Settings:
iscsi:”192.168.0.2”:”3261”:”000000000000000E”:”iqn.2009-4.com:12345
67890”::”E”::”E”
where the following is:
Target IP address: 192.168.0.2
Target TCP port: 3261
Target boot LUN: 0x0E
Target iqn name: iqn.2009-04.com:1234567890
Initiator name: Not specified. Use the Initiator name already configured. Use the
default name if none was configured.
It is hexadecimal representation of Logical Unit number of
the boot device. If not provided, LUN 0 is assumed to be
the boot LUN. It is an eight-byte number which should be
specified as a hexadecimal number consisting of 16 digits,
with an appropriate number of 0’s padded to the left, if
required. Optional
Replace it with a valid iSCSI target iqn name of up to 223
characters. Mandatory
Replace it with a valid iSCSI iqn name of up to 223
characters. If not provided the default Initiator name
(generated by the adapter based on the board’s MAC
address) will be used. Optional
Replace it with either “E” or “D”.
• “E” denotes header digest is enabled
• “D” denotes that it is disabled. Optional
Replace it with either “E” or “D”.
• “E” denotes data digest is enabled and
• “D” denotes that it is disabled.
If not provided it is assumed that Data Digest is disabled by
default. Optional
If applicable replace it with “D”, “E” or “M”.
• “D” denotes authentication is disabled,
• “E” denotes that one-way CHAP is enabled - the
username and secret to be used for oneway CHAP must
be specified by non-DHCP means
• “M” denotes that MutualCHAP is enabled - user name
and passwords required for mutual CHAP authentication
must be specified by non-DHCP means.
If not specified, this field defaults to authentication
disabled.
Optional
Table 4-9 Data String Parameters for Option 43 (Continued)
Parameter Description Field Type
