Boot Version 10.2 for NIC, iSCSI, FCoE, and RoCE Protocols User Manual P010097-01B Rev. A
Appendix F. Dell UEFI
Main Configuration Page
1774
iSCSI Initiator Parameters Page
This page allows you to configure the iSCSI initiator parameters.
Figure F-9 iSCSI Initiator Parameters Page
Table F-8 iSCSI Initiator Parameters Page Menu Options
Menu Option Description and Available Settings
IP Address Specify the iSCSI initiator’s IP address. The value should be in either
IPv4 or IPv6 format and can be 2–39 characters long.
IPv4 Address Specify the iSCSI initiator’s IPv4 address. The value must be in IPv4
format and can be 7–15 characters long.
IPv6 Address Specify the iSCSI initiator’s IPv6 address. The value must be in IPv6
format and can be 2–39 characters long.
Subnet Mask Specify the iSCSI initiator’s IPv4 subnet mask. The value must be in
IPv4 format and can be 7–15 characters long.
Subnet Mask Prefix Specify the iSCSI initiator’s IPv6 subnet mask. The value must be in
IPv6 format and can be 2–39 characters long.
Default Gateway Specify the iSCSI initiator’s default gateway. The value should be in
either IPv4 or IPv6 format and can be 2–39 characters long.
IPv4 Default Gateway Specify the iSCSI initiator’s IPv4 default gateway. The value must be
in IPv4 format and can be 7–15 characters long.
IPv6 Default Gateway Specify the iSCSI initiator’s IPv6 default gateway The value must be
in IPv6 format and can be 2–39 characters long.
iSCSI Name Specify the initiator iSCSI Qualified Name (IQN). The valid range is
0–223 characters.
